| MODEL |
MPA-60 |
| Power Output (at 4Ω) |
RMS 60W / MAX 70W |
| Frequency Response |
80Hz – 16kHz ± 3 dB |
| Power Supply |
AC: 115~230V 50/60Hz switchable, DC 24V |
| Input / Sensitivity |
MIC: -52dBv balanced |
| Phantom: -52dBv 24V balanced |
| Line: -10dBv unbalanced |
| AUX: -6dBv balanced |
| AMP in: 0dBv unbalanced |
| Tel: -10dBv balanced |
| THD |
<0.1% |
| S/N Ratio |
MIC > 65dB / AUX > 80dB / Phone > 65dB / Line > 75dB |
| Output (Ω) |
4Ω |
| Output (V) |
25V, 70V, 100V |
| Controls |
3 INPUT volume |
| 1 AUX volume |
| 1 MASTER volume |
| 2 Treble / Bass |
| Tel input & Monitor |
| BGM Module |
MP3-300 MP3 player |
| Dimension (W x D x H) |
420 x 260 x 88 mm (16.5’’ x 10.2’’ x 3.5’’) |
| Weight |
6.5 kg (14.4 lbs) |
