| Model |
TPS i15H |
| System Type |
2-Way Vented Cabinet |
| Transducer Low |
15″ Woofer – 2″ Voice Coil |
| Transducer Driver |
1” Driver – 1” Voice Coil |
| Frequency Response |
50Hz~20KHz (-6dB) |
| Crossover Frequency |
2.8KHz |
| Horn Coverage |
50º× 50º |
| Nominal Impedance |
8 Ohms |
| Max SPL |
96dB / 122dB (Max) |
| Power Rating |
200W Continuous / 400W Program |
| Input Connector |
2 × SPK4 |
| Electronic Protection |
High Frequency Protection |
| Enclosure Construction |
Plywood cabinet, resistant black paint, metal grille, rubber feet, two handles |
| Dimensions (HxWxD) |
65.5 x 42.2 x 40 |
| Net Weight |
16,8 |
